Frontier™ Loader Attachments
HP20 Series Hydraulic Power Pack
Overview:
- Thermal switch protects hydraulic system
- Rear quick connects
- Optional oil cooler unit
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. This information is provided for illustrative purposes only and does not constitute an application.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
Thermal switch protects hydraulic system
Protective thermal switch
A thermal switch protects the hydraulic system when the hydraulic oil reaches 93 °C (200 °F).
Rear quick connect makes hookups convenient
Convenient hydraulic hookup
Rear quick connect makes for fast and easy connections.
Optional oil cooler unit
Oil cooler unit
The optional oil cooler unit regulates the temperature of the hydraulic fluid for warmer weather implements.
Specifications
Key Specs
| Unit width | 965 mm 38 in. |
|---|---|
| Unit width with weights | 1,524 mm 60 in. |
| Unit height | 1,321 mm 52 in. |
| Unit length | 762 mm 30 in. |
| Counter weight support | 700, accepts John Deere weights: 19.1 kg 42 lb and 31.8 kg 70 lb |
| Hitch - Category | Category 1 |
| Quick hitch, Category 2 | No |
| PTO horsepower | 18.6-26.1 kW 25-35 hp |
| PTO rpm | 540 PTO |
| Loader (current John Deere series) | 300 |
Dimensions
| Unit width | 965 mm 38 in. |
|---|---|
| Unit width with weights | 1,524 mm 60 in. |
| Unit height | 1,321 mm 52 in. |
| Unit length | 762 mm 30 in. |
Weight
| Operating | 1,177 kg 535 lb |
|---|---|
| Shipping | 1177 kg 535 lb |
Tractor requirements
| PTO horsepower | 18.6-26.1 kW 25-35 hp |
|---|---|
| PTO rpm | 540 PTO |
| Loader (current John Deere series) | 300 |
Hitch
| Category | Category 1 |
|---|---|
| Quick hitch, Category 2 | No |
Hydraulics
| Relief valve setting | 207 bar 3,000 psi |
|---|---|
| Oil cooler | Standard |
| Flow @ 3000 psi (207 bar) | 60.6 L/min 16 gpm |
| Oil reservoir | 56.8 L 15 U.S. gal. |
| Hose diameter | 19 mm 0.75 in. |
| Tank-mounted strainer | Standard |
| Tank-mounted return filter | Standard, with breather |
| Pump rpm | 1,836 rpm |
Miscellaneous
| Parking stands | Standard |
|---|---|
| Counter weight support | 700, accepts John Deere weights: 19.1 kg 42 lb and 31.8 kg 70 lb |
Shipping
| Configuration | One unit |
|---|
Set-up time
| Labor hours | 1.5-2 |
|---|
Warranty
| Time period (machine) | 1 year |
|---|
